LP20 14PIN Industrial Waterproof Connector IP68 Quickly Plugging Aviation Connector Solder-Assembly M22 14PIN Circular Connector Fast Release Electrical Connector Female Plug&Male Socket
Product details
| Management number | 247733267 | Release Date | 2026/08/16 | List Price | US$6.40 | Model Number | 247733267 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- E-WeiChat LP20 Connector: Circular Connector Kit comprises an M22 female plug and a straight-through male socket. This connector kit features a one-touch mating mechanism, ensuring a secure connection whilst providing a smooth and hassle-free user experience. Protection rating: IP68 (when mated); Mounting method: Soldering.
- Standard Specifications: E-WeiChat LP20 Quick-Plugging Aviation Connector,supports multiple pin configurations (2–14 pins) with cable outer diameters of Φ5–Φ12 mm and wire gauges ranging from 0.34–4 mm² (22–12 AWG). Rated up to 30A/500V AC (600V AC for stamped plastic versions), ≥1900 mating cycles, and an operating temperature range of -40°C to +85°C. do not plug or unplug whilst the power is on.
- Superior IP68 waterproof protection: This practical waterproof connector features a tight silicone seal, providing excellent dust and moisture resistance when fully mated. As a robust circular connector, it withstands harsh outdoor and industrial environments, ensuring a safe and stable electrical connection at all times.
- PBT Plastic Housing with Metal Shell Solder-Type Connector: This solder-type aviation connector is constructed from a high-quality PBT plastic housing, whilst the metal push-to-connect mechanism offers excellent resistance to ageing, high temperatures and impact. The internal gold-plated copper alloy pins ensure stable conductivity and resistance to oxidation, significantly extending the service life of this quick-connect aviation connector.
- Wide Application:Universal Waterproof Circular Connector is ideal for power and signal connection, widely applied in automation equipment, outdoor lighting, LED screen, instrumentation, household electronics, vehicle equipment and other fields, perfect for all kinds of daily and industrial wiring connection needs.
| ASIN | B0H2GP9HPV |
|---|---|
| Item Weight | 3.52 ounces |
| Manufacturer | E-WeiChat |
| Package Dimensions | 7.09 x 5.91 x 1.18 inches |
